1500×5000 CNC Horizontal Type V-Cut Machine For Stainless Steel ,CNC Grooving Machine,CNC V Cutting Machine
Features: 1) RGHK series V-grooving machine is an upgrade product of traditional planer. 2) RGHK high-speed CNC grooving machine for thin plate adopts precision ball screw as power transmission component, which with high machining accuracy is especially important for high-grade products. 3) For material clamping device, hydraulic system is used as power , it brings high pressure, reliable fastening, low noise and low energy consumption. 4) Adopt frame structure, connected with high strength bolt, through heat treatment to eliminate stress of worktable, to ensure overall rigidity and reduce deformation. 5) When this machine working, the beam is fixed, the workpiece is conveyed by after by back-feed mechanism. The working surface is made of carbon steel,the high frequency surface hardness achieve 55 to 60 HRC after quenching (ordinary mesa < 30 HRC), which makes workbench is stiffer than stainless steel, it keeps the workbenth surface flatness ≤±0.03mm, avoid scratches caused of low hardness. This technology makes sure the precision of v groove and extends the service life of the equipment. 6) There are supporting devices equipped in the front and back of the workbenth to prevent scratching the metal plate material in the process. 7) The CNC system is easy to master and operate. As long as the processing parameters are input, the equipment will be processed automatically, and there are multiple interlocking safeguards to ensure the safe operation of the equipment. 8) Mainly electrical components are imported, in line with international standards, safe and reliable, long life, anti-interference ability, and electric control cabinet is equipped with heat sink.
