Smart CNC not only produce Press Brake, Laser Machine,Shear, Rolling Machine, also supply other complete sheet metal machine solution.
| Place of Origin: | China |
|---|---|
| Brand Name: | SMART CNC |
| Certification: | CE,ISO,TUV |
| Model Number: | EB5-600/4000 |
| Minimum Order Quantity: | 1 sets |
| Packaging Details: | Wooden case |
| Delivery Time: | 2 months |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 sets/months |
| Condition: | New | Power: | Hydraulic |
|---|---|---|---|
| Automation: | Automatic | Color: | Customized |
| Nominal Pressure (kn): | 6000 | Length: | 4000mm |
| Highlight: | 600 Ton NC Press Brake,Stainless Steel 16mm Press Brake,4000mm NC Press Brake |
||
Hydraulic NC/CNC Press Brake 600Ton For Mild Steel And Stainless Steel 16mm
SPECIFICATION FEATURE:
All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity and stability.
Torsion shaft forced synchronization of mechnaical limit stopper balance, with high precision.
Integrated hydraulic transmission system, large range of speed regulation thanks to transmission of thesliding block, stable and reliable performance.
Rear stopper and the sliding block have electrical adjustment for their stroke, with manual fine tuning, and
digital indication.
Adjustment mechanism of sliding block independent from oil cylinder assembly to enhance sealing effect upper mold is fitted with tilting warp offset mechanism.
For bending machine from 250 t up synchronization mechanism of mechanical or electrical hydraulic transmission is fitted, lower working table is fitted with warp offset mechnaism. Multi machine combined operation is possible
| No | Name | EB5-600/4000 |
| 1 | Nominal pressure | 6000 KN |
| 2 | Working table length | 4000 mm |
| 3 | Distance between uprights | 3100 mm |
| 4 | Ram stroke | 300 mm |
| 5 | Max.opening height | 650mm |
| 6 | Throat depth | 500 mm |
| 7 | Approaching speed | 80 mm/s |
| 8 | Working speed | 8-12 mm/s |
| 9 | Returning speed | 60 mm/s |
| 10 | Main Motor power | 37kw |
| 11 | Overall dim. (L*W*H) | 4500*3000*3600mm |
| 12 | Weight | 37,500 KGS |
