Wuxi Smart CNC Equipment Group Co.,LTD
“Quality First, Customer First”
Smart CNC not only produce Press Brake, Laser Machine,Shear, Rolling Machine, also supply other complete sheet metal machine solution.
| Place of Origin: | China |
|---|---|
| Brand Name: | SMART CNC |
| Certification: | CE ISO TUV |
| Model Number: | WC67K-40/2500 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Nude |
| Delivery Time: | 50 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50 set/month |
| Name: | Hydraulic NC Bending Machine | Pressure: | 400KN |
|---|---|---|---|
| Motor: | China | Valve: | Taiwan |
| Electrical: | Schneider | Delivery Time: | 20days |
| Frame Thicknes: | 50 Mm | Types: | Torsion Bar |
| Highlight: | steel bar bending machine,hydraulic press bending machine |
||
Hydraulic Nc Press Brake 40 Ton Small Press Brake Mini Press Brake Steel Bending Machine
Product Description
Hydraulic press brake is a steel sheet bending machine, it is composed by supporting frame, worktable and pressing board. The main frame is processed by annealing art, long time using, there is no shape changing, keep high bending precision. Bending die is processed by special art.
Hydraulic press brake also named CNC press brake, CNC steel sheet bending machine, electric-hydraulic synchronized CNC press brake, NC steel sheet bending machine. Which is mainly used for steel sheet bending or stainless bending. Mainly in steel metal processing industry. Like cabinet processing, decoration, electrical lift surface wrapping, and other steel metal or stainless board processing industry.
WC67Y/WC67K Series Technical Parameters
| Model |
Nominal pressure (mm) |
Worktable length (mm) |
Distance between housings (mm) |
Throat depth (mm) |
Stroke (mm) |
Max. opening height (mm) |
Power (KW) |
Dimension LxWxH (mm) |
| 30T/1600 | 300 | 1600 | 1280 | 200 | 80 | 285 | 3 | 1600x1000x1600 |
| 35T/2000 | 350 | 2000 | 1480 | 200 | 80 | 285 | 4 | 2000x1100x1800 |
| 40T/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200x1200x1910 |
| 40T/2500 | 400 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x1910 |
| 50T/2500 | 500 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500x1200x2000 |
| 63T/2500 | 630 | 2500 | 1900 | 250 | 100 | 320 | 5.5 | 2500x1300x2210 |
| 63T/3200 | 630 | 3200 | 2500 | 250 | 100 | 320 | 5.5 | 3200x1300x2210 |
| 80T/2500 | 800 | 2500 | 1900 | 300 | 100 | 320 | 7.5 | 2500x1400x2300 |
| 80T/3200 | 800 | 3200 | 2500 | 320 | 100 | 350 | 7.5 | 3200x1500x2300 |
| 80T/4000 | 800 | 4000 | 3000 | 320 | 100 | 350 | 7.5 | 4000x1500x2400 |
| 100T/2500 | 1000 | 2500 | 1900 | 320 | 120 | 320 | 7.5 | 2500x1600x2400 |
| 100T/3200 | 1000 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 100T/4000 | 1000 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 125T/3200 | 1250 | 3200 | 2500 | 320 | 120 | 370 | 7.5 | 3200x1600x2600 |
| 125T/4000 | 1250 | 4000 | 3000 | 320 | 120 | 370 | 7.5 | 4000x1600x2700 |
| 160T/3200 | 1600 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1700x2700 |
| 160T/4000 | 1600 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1700x2800 |
| 160T/5000 | 1600 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1900x3100 |
| 160T/6000 | 1600 | 6000 | 4940 | 320 | 200 | 460 | 11 | 6000x1900x3200 |
| 200T/3200 | 2000 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200x1950x2800 |
| 200T/4000 | 2000 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000x1950x2800 |
| 200T/5000 | 2000 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000x1950x3000 |
| 200T/6000 | 2000 | 6000 | 5000 | 320 | 200 | 460 | 11 | 6000x1950x3300 |
| 250T/3200 | 2500 | 3200 | 2500 | 400 | 250 | 590 | 18.5 | 3200x2000x3200 |
| 250T/4000 | 2500 | 4000 | 3000 | 400 | 250 | 590 | 18.5 | 4000x2000x3400 |
| 250T/5000 | 2500 | 5000 | 4000 | 400 | 250 | 590 | 18.5 | 5000x2000x3400 |
| 250T/6000 | 2500 | 6000 | 5000 | 400 | 250 | 590 | 18.5 | 6000x2000x3400 |
| 300T/3200 | 3000 | 3200 | 2530 | 400 | 250 | 590 | 22 | 3200x2000x3450 |
| 300T/4000 | 3000 | 4000 | 3000 | 400 | 250 | 590 | 22 | 4000x2000x3450 |
| 300T/5000 | 3000 | 5000 | 4000 | 400 | 250 | 590 | 22 | 5000x2000x3450 |
| 300T/6000 | 3000 | 6000 | 5000 | 400 | 250 | 590 | 22 | 6000x2000x3450 |
| 400T/4000 | 4000 | 4000 | 3000 | 400 | 250 | 590 | 30 | 4000x2180x3400 |
| 400T/5000 | 4000 | 5000 | 4000 | 400 | 250 | 590 | 30 | 5000x2180x3500 |
| 400T/6000 | 4000 | 6000 | 5000 | 400 | 250 | 590 | 30 | 6000x2180x3800 |
| 500T/5000 | 5000 | 5000 | 4000 | 400 | 250 | 590 | 45 | 5050x3500x3700 |
| 500T/6000 | 5000 | 6000 | 5000 | 400 | 320 | 590 | 45 | 6050x3500x3700 |
| 600T/4000 | 6000 | 4000 | 3000 | 400 | 320 | 590 | 55 | 4050x4500x3700 |
| 600T/6000 | 6000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6050x4500x3700 |
| 800T/6000 | 8000 | 6000 | 5000 | 400 | 320 | 590 | 55 | 6300x4500x6000 |
Note: No notice if any changes of the above statistics made.
